Thông số kỹ thuật
Power amplifi er section
Rated output
70 W + 70 W
(20 Hz – 20 kHz, 8 ohms, T.H.D. 0.07%)
140 W + 140 W
(1 kHz, 4 ohms, T.H.D. 0.7%)
Total harmonic distortion
0.01% (rated output -3 dB, 8 ohms, 1 kHz)
Preamplifier section
Input sensitivity / Impedance
PHONO MC
0.2 mV/100 ohms
PHONO MM
2.5 mV/47 kohms
LINE
125 mV/47 kohms (Source Direct: OFF)
Signal-to-noise ratio
PHONO MC
74 dB (0.5 mV input)
PHONO MM
89 dB (5 mV input)
LINE
108 dB
Tone control
Treble
± 8 dB at 10 kHz
Bass
± 8 dB at 100 Hz
General
Power supply
AC 230 V, 50/60 Hz
Power consumption
295 W (Standby: 0.2 W)
Dimensions (W x H x D)
434 x 135 x 414 mm
Weight
16.1 kg
Port
IN
– Phono (MM/MC) x 1
– Audio input (incl. Phono) x 6
– Power Amp Direct x 1
OUT
– Pre Out x 1
– Rec output x 1
– Speaker out (Bi-wiring) A/B
